Product Description:
The Conveyor Belt Cleaner is a secondary belt cleaner designed for
use in a wide range of industrial applications. This tungsren
carbide belt cleaning scraper is designed for use on conveyor belts
with a width of 500mm-2200mm and it has an operating temperature of
less than 90℃. It is also designed to work in environments with a
material humidity of less than 15%. It features a belt cleaning
scraper blade that can easily remove debris from the conveyor belt.
This belt cleaner is designed to be easy to install and maintain
and offers a reliable and efficient performance.
A tungsten carbide belt cleaner is a type of conveyor belt cleaner
that utilizes tungsten carbide as the primary material for the
cleaning blade. Tungsten carbide is a very hard and wear-resistant
material that is well-suited for abrasive and high-wear
applications.Features:
DB-DTEH H-type Primary belt cleaner features its cleaner blades,
which have tungsten carbide tips. Tungsten carbide offers excellent
wear resistance, so longer service life is possible.
DTEP P-Type Secondary Belt Cleaner is used to clean the return
belt, which is installed on the place where the belt leaves the
head pulley.
Technical Parameters:
Applications:
DB-DTEH / DB-DTEP Tungsten carbide belt cleaners are commonly used
in industries such as mining, cement, aggregate, and recycling,
where high levels of abrasion and wear are experienced. Their wear
resistance, cleaning efficiency, and longevity make them suitable
for protecting conveyor belts and improving overall conveyor
performance.
Belt cleaner celection
Ordering Information:
1.Belt width
2.Belt speed
3.Material conveyed(coal, sand, rock, etc.)
4.Material conditions, dry, wet, sticky, etc.
5.Working temperature
6. Conveyor belt splice type: mechanical or vulcanized
7.If the belt is reversible
As long as you confirm the details above then the exact prices will
be offered .
It’s important to consider the specific application requirements
and consult with JIAOZUO DEBON TECHNOLOGY to choose the appropriate
conveyor belt cleaner for a particular conveyor system.
